Internal & External Application
High Speed-High Performance Fast Door High Speed-High Performance Fast Door High Speed-High Performance Fast Door High Speed-High Performance Fast Door High Speed-High Performance Fast Door

High Speed-High Performance Fast Door

:    PRO5041
:    Toshi Supreme I
:    73083000
Reseller can buy the product Consumer can buy the product
In Stock
184,575 277,500 You save 92,925
What is in the Package

High Speed Door size upto 3000mm * 3000mm : 1 Nos. (As per Photograph) Safety Sensor : 1 Nos. Wireless Safety Edge : 1 Nos. In Built German Motor and Control Panel : 1 Set Push Button : 2 Nos.

Description

High Speed-High Performance Roll Fast Door - Supreme- I - S1 (Internal)
Size Width upto 3000mm  and Height upto 3000mm

Technical Specification :-
Application : Internal
Door Size : Max Width Upto 6000mm (Extra charge)
Max Height : Upto 6000mm     (Extra Charge(
Opening Speed : 0.8m/sec – Standard
Closing Speed : 0.8m/sec – Standard
Safety Features : Safety Sensor – Standard
Safety Edge – Standard
Wind Resistance : Equivalent to EN 12424 – Class 2
Wind Bar : Aluminum Extruded Profiles – Standard 4 to 5 Nos.
See Through : One Row with 1/2 Wndows in 2 mm thick PVC
Door Curtain : 900 gm / Per square Meter – Standard
Optional : 1400-1800 gm/ Per square Meter (at extra cost)
Side Vertical Guide : Anodized /Colourded Aluminum Profile – Standard
Galvanized / Stainless Steel – Optional (at extra cost)
Anti Crash System : Inbuilt – Standard
Top Shaft    : Aluminum/MS – Standard
Motor & Controller :    High Duty Cycle German Motor with limit box / Brake / Gear assembly
-400 v 3ph, N with Standard Open – Stop – Close Controller
(IP65 Box Rating)
VFD Controller Optional (at extra cost)
Emergency Off Button – Optional (at extra cost)
Manual Operation : Crank Handle – Standard - To open door in Power Failure Mode
Power Requirement :     Upto 2 Kw
